Wheel Collection

Product image shown not representative of all configurations. Vehicle specific fitment will change offset, dish and center profile. Please consult your salesperson for application-specific details.

Details

Refined and redesigned in multiple widths, diameters, and exclusive finishes. Innovative new engineering and casting methods yield stronger, lighter wheels while retaining the signature Rotiform look.

18x8.5, 19x8.5


Patent# D853935, D853933

Technical Specs

Size BP BP 2 Part Number Finish Bore Offset BSM (in) Cap Num Rating (lb) Weight (lb) Lug Type LipSize (in)
17X9 5x127 R150179075+01 MATTE BRONZE BLACK BEAD RING 71.50 1 5.040 1004-40BR 2500 31 Conical 0
17X9 6x139.7 R150179084+01 MATTE BRONZE BLACK BEAD RING 106.10 1 5.040 1004-40BR 2500 31 Conical 0
17X9 6x135 R150179089+01 MATTE BRONZE BLACK BEAD RING 87.10 1 5.040 1004-40BR 2500 31 Conical 0
17X9 6x139.7 R151179084+01 MATTE BLACK 106.10 1 5.040 1004-40MB 2500 31 Conical 0
17X9 6x135 R151179089+01 MATTE BLACK 87.10 1 5.040 1004-40MB 2500 31 Conical 0
17X9 5x120 R1511790A3+20 MATTE BLACK 65.07 20 5.790 1004-40MB 2500 31 Ball 0
Size BP BP 2 Part Number Finish Bore Offset BSM (in) Cap Num Rating (lb) Weight (lb) Lug Type LipSize (in)
18X8.50 5x100 5x112 R113188514+35 MATTE BLACK 66.56 35 6.130 36390-02MB 1600 29 Conical
18X8.50 5x100 5x112 R113188514+45 MATTE BLACK 66.56 45 6.520 36390-02MB 1600 29 Conical 0
18X8.50 5x100 5x112 R1131885F3+35 MATTE BLACK 66.60 35 6.130 36390-02MB 1600 29 Conical
18X8.50 5x100 5x112 R1131885F3+45 MATTE BLACK 66.60 45 6.520 36390-02MB 1600 29 Conical 0
18X8.50 5x100 5x112 R114188514+35 GLOSS SILVER 66.56 35 6.130 36390-02GS 1600 29 Conical
18X8.50 5x100 5x112 R114188514+45 GLOSS SILVER 66.60 45 6.520 36390-02GS 1600 29 Conical
18X8.50 5x100 5x112 R1141885F3+35 GLOSS SILVER 66.60 35 6.130 36390-02GS 1600 29 Conical
18X8.50 5x100 5x112 R1141885F3+45 GLOSS SILVER 66.60 45 6.520 36390-02GS 1600 29 Conical
18X8.50 5x100 5x112 R118188514+45 MATTE GOLD 66.56 45 6.520 36390-02MG 1600 29 Conical
18X8.50 5x100 5x112 R1181885F3+45 MATTE GOLD 66.60 45 6.520 36390-02MG 1600 29 Conical
Size BP BP 2 Part Number Finish Bore Offset BSM (in) Cap Num Rating (lb) Weight (lb) Lug Type LipSize (in)
19X8.50 5x100 5x112 R113198514+35 MATTE BLACK 66.60 35 6.130 36390-02MB 1600 31 Conical
19X8.50 5x100 5x112 R113198514+45 MATTE BLACK 66.56 45 6.520 36390-02MB 1600 30 Conical 0
19X8.50 5x108 5x112 R1131985E8+45 MATTE BLACK 72.60 45 6.520 36390-02MB 1600 29 Conical 0
19X8.50 5x100 5x112 R1131985F3+35 MATTE BLACK 66.60 35 6.130 36390-02MB 1600 31 Conical
19X8.50 5x100 5x112 R1131985F3+45 MATTE BLACK 66.60 45 6.520 36390-02MB 1600 31 Conical 0
19X8.50 5x100 5x112 R114198514+35 GLOSS SILVER 66.60 35 6.130 36390-02GS 1600 31 Conical
19X8.50 5x100 5x112 R114198514+45 GLOSS SILVER 66.60 45 6.520 36390-02GS 1600 31 Conical 0
19X8.50 5x108 5x112 R1141985E8+45 GLOSS SILVER 72.60 45 6.520 36390-02GS 1600 29 Conical 0
19X8.50 5x100 5x112 R1141985F3+35 GLOSS SILVER 66.60 35 6.130 36390-02GS 1600 31 Conical
19X8.50 5x100 5x112 R1141985F3+45 GLOSS SILVER 66.60 45 6.520 36390-02GS 1600 31 Conical 0
19X8.50 5x108 5x112 R1141985F5+45 GLOSS SILVER 72.70 45 6.520 36390-02GS 1600 31 Conical 0
Size BP BP 2 Part Number Finish Bore Offset BSM (in) Cap Num Rating (lb) Weight (lb) Lug Type LipSize (in)
20X9 6x139.7 R150209083+01 MATTE BRONZE BLACK BEAD RING 108 1 5.040 1004-40BR 2500 38 Conical 0
20X9 6x135 R150209089+01 MATTE BRONZE BLACK BEAD RING 87.10 1 5.040 1004-40BR 2500 38 Conical 0
20X9 5x130 R151209029+30 MATTE BLACK 84.10 30 6.180 1004-40MB 2500 39 Ball 0
20X9 5x130 R151209046+30 MATTE BLACK 84.10 30 6.180 1004-40MB 2500 38 Conical 0
20X9 6x139.7 R151209083+01 MATTE BLACK 108 1 5.040 1004-40MB 2500 38 Conical 0
20X9 6x135 R151209089+01 MATTE BLACK 87.10 1 5.040 1004-40MB 2500 38 Conical 0
